JGA262251 - Square D 225A 600V 2 Pole I-Line Molded Case Circuit Breaker

JGA262251

JGA262251 is a Square D 2 pole, 225 amp, 600 volt I-Line molded case circuit breaker designed for reliable power distribution protection.This circuit breaker features a thermal-magnetic trip unit with a current limiting design, suitable for Class 611/612 I-Line panelboards and switchboards. It offers an interrupt rating of 18kA at 600 VAC and complies with UL, CSA, and CE certifications. The breaker uses a plug-in mounting type and is built to meet demanding industrial and commercial electrical system requirements.

• Amperage: 225 A
• Voltage Rating: 600 V AC
• Number of Poles: 2
• Mounting Type: I-Line Plug-In
• Interrupt Rating: 18 kA at 600 VAC
• Trip Unit: Thermal Magnetic
• Series/Frame: PowerPact J-Frame
• Certifications: UL, CSA, CE
• Current Limiting Type
• Designed for Class 611/612 I-Line Panelboards
• Country of Origin: USA

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: JGA262251
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : JGA
• Voltage : 600
• Amperage : 225
• Phase : 1
• Poles : 2
• AIC rating : 35kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Lug
• Frame Size : 250A/JG
• Temp Rating : 28-158 °F (-2-70 °C)
• MCM Size : Min. Wire Size 3/0 AWG Max. Wire Size 300 MCM
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : AB

Product Data

• UPC : 785901511687
• GTIN : 00785901511687
• Country of Origin : United States
• Dimensions : 7.5 in (191 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 4.5
• Panel Type : I Line Panelboards
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 3/0...350 kcmil aluminium/copper terminals
