JGA262002 - Square D 200A 2-Pole 600V PowerPact J Thermal Magnetic Circuit Breaker

JGA262002

JGA262002 is a Square D 200 amp, 2-pole, 600 Volt PowerPact J molded case circuit breaker with thermal magnetic trip unit designed for reliable overcurrent protection.This circuit breaker features an 18kA interrupt rating at 600VAC, I-Line mounting, and is UL 489 listed with CSA, NOM, IEC, CCC, UKCA, and CE certifications. It provides efficient switching and protection for AC systems with a magnetic trip current of 2000A and hold current of 1000A.

• Amperage: 200A
• Voltage Rating: 600VAC
• Poles: 2
• Interrupt Rating: 18kA at 600VAC
• Mounting Type: I-Line
• Trip Unit: Thermal Magnetic
• Series/Frame: PowerPact J
• Certifications: UL 489, CSA, NOM, IEC, CCC, UKCA, CE
• Magnetic Trip Current: 2000A
• Magnetic Hold Current: 1000A
• Environmental: Recyclable packaging

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: JGA262002
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : JGA
• Voltage : 600
• Amperage : 200
• Phase : 1
• Poles : 2
• AIC rating : 35kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Lug
• Frame Size : 250A/JG
• Temp Rating : 28-158 °F (-2-70 °C)
• MCM Size : Min. Wire Size 4 AWG Max. Wire Size 4/0 AWG
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : AC

Product Data

• UPC : 785901511724
• GTIN : 00785901511724
• Country of Origin : United States
• Dimensions : 7.5 in (191 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 4.5
• Panel Type : I Line Panelboards
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 3/0...350 kcmil aluminium/copper terminals
