JDP34250WU31X - Schneider Electric Square D PowerPacT J 250A 3P 480V 18kAIC Bolt-On Molded Case Circuit Breaker with Standard Trip Unit

JDP34250WU31X

JDP34250WU31X is a Schneider Electric Square D PowerPacT J molded case circuit breaker designed for reliable overcurrent protection in commercial and industrial applications.

This 3-pole, bolt-on circuit breaker features a 250A current rating, 480V voltage rating, and an 18kA interrupting capacity at 480V. It is equipped with a standard 3.2-W non-interchangeable trip unit, offering both long-time and instantaneous (LI) trip functions for precise protection. The breaker is UL listed, suitable for reverse fed applications, and includes load side lug terminals for secure connections.

Key Specifications
• Part Number: JDP34250WU31X
• Manufacturer: Schneider Electric / Square D
• Series/Frame: PowerPacT J
• Amperage: 250A
• Voltage: 480V
• Poles: 3
• Mounting Type: Bolt-On
• Interrupt Rating: 18kA @ 480V
• Trip Unit: Standard 3.2-W, LI (Long-Time and Instantaneous)
• Certifications: UL Listed
• Terminals: Load side lugs
• Application: Suitable for reverse fed installations
• Construction: Molded case, solid state

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: JDP34250WU31X
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : JDP
• Voltage : 480
• Amperage : 250
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : J Frame
• Protection : Solid State

Product Data

• GTIN : 03606486283585
• Weight : 5
