JDL36200AASA - Square D 200A 600V 3-Pole Powerpact JDL Molded Case Circuit Breaker, Unit Mount, 18kA@480V Interrupt Rating

JDL36200AASA

JDL36200AASA is a Square D Powerpact JDL series molded case circuit breaker rated for 200 amps, 600 volts, and 3 poles with unit mount installation.This thermal-magnetic circuit breaker features a 3-pole design with a 200 amp line rated current and a standard interrupting capacity of 18kA at 480V. It includes long-time and instantaneous trip functions, feed-thru lugs for line and load connections, and is UL, CSA, and CE certified. The breaker has a J-frame type, toggle control, and supports AWG 4 to 4/0 aluminum or copper terminals.

Key Specifications
• Amperage: 200A
• Voltage: 600V AC
• Poles: 3
• Frame Type: JDL (J-Frame)
• Interrupt Rating: 18kA at 480V
• Mounting Type: Unit Mount
• Trip Unit: Thermal Magnetic with Long-Time and Instantaneous
• Connection: Feed-Thru Lugs (Line and Load)
• Certifications: UL, CSA, CE
• Control Type: Toggle
• Magnetic Hold Current: 2000A
• Dimensions: 7.52" H x 4.12" W x 5" D

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

complete with 1A/1B auxiliary switch and 110/130Vac shunt trip

Specifications

• Part Number: JDL36200AASA
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : JDL
• Voltage : 600
• Amperage : 200
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : Feed-Thru
• Functions : Long-Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901630647
• GTIN : 00785901630647
• Dimensions : 7.5 in (191 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 5
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 3/0...350 kcmil aluminium/copper terminals
