2 Year Warranty Guaranteed
All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.
Product Questions? Contact Us
Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
JDL36175SA
JDL36175SA is a Square D PowerPact J Frame molded case circuit breaker designed for reliable protection in industrial and commercial power distribution systems. This unit mount breaker features a 175A current rating, 600VAC maximum voltage, and three poles for versatile circuit protection. The breaker is equipped with a thermal magnetic trip unit and a shunt trip for remote operation, making it suitable for a wide range of applications. It is UL 489 listed and meets CSA and CE standards for safety and performance. This molded case circuit breaker is built for durability and ease of installation, with a compact design and robust interrupting ratings. The JDL36175SA is ideal for use in environments requiring high reliability and compliance with industry standards.
- Part Number: JDL36175SA
- Manufacturer: Square D
- Series/Frame: PowerPact J Frame
- Amperage: 175A
- Voltage: 600VAC, 250VDC
- Poles: 3 Pole
- Mounting Type: Unit Mount
- Interrupt Rating: 14kA @ 600VAC
- Trip Unit: Thermal Magnetic with Shunt Trip
- Certifications: UL 489, CSA, CE
- Width: 4.09 inches
- Depth: 3.39 inches
- Height: 7.52 inches
Additional Information
complete with 110/130Vac shunt trip
Specifications
- Part Number: JDL36175SA
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Powerpact
- Type : JDL
- Voltage : 600
- Amperage : 175
- Phase : 3
- Poles : 3
- AIC rating : 18kA@480V
- Connection : Feed-Thru
- Functions : Long-Time and Instantaneous Trip
- Terminal Connection : Lug
- Frame Size : J
- Temp Rating : -13–158 °F (-25–70 °C)
- MCM Size : Min. Wire Size 4 AWG (Cu/Al) Max. Wire Size 4/0 AWG (Cu/Al)
- Protection : Thermal Magnetic
Product Data
- UPC : 785901835752
- GTIN : 00785901835752
- Country of Origin : United States
- Dimensions : 7.5 in (191 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
- Weight : 5.27
- Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
- Certification : UL, CSA, NOM
- Wire Size : AWG 4...AWG 4/0 aluminium/copper terminal
