Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
JDC3225W
JDC3225W is an Eaton Series C complete molded case circuit breaker designed for reliable circuit protection in industrial and commercial applications.This J-frame JD type breaker features a fixed thermal and fixed magnetic trip unit, providing dependable overcurrent protection. It is a three-pole breaker rated for 225 amps at 600 volts AC and 250 volts DC. The breaker supports bolt-on mounting and offers an interrupt rating of 200 kAIC at 240 VAC, ensuring high fault current interruption capability.
- Manufacturer: Eaton
- Series: Series C, J-frame, JD type
- Amperage: 225 A
- Voltage Rating: 600 VAC, 250 VDC
- Poles: 3
- Trip Type: Fixed thermal, fixed magnetic
- Interrupt Rating: 200 kAIC at 240 VAC
- Mounting Type: Bolt-On
Additional Information
This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.
Specifications
- Part Number: JDC3225W
- Manufacturer : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : JDC
- Voltage : 600
- Amperage : 225
- Phase : 3
- Poles : 3
- AIC rating : 100kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : J Frame
- Protection : Thermal Magnetic
Product Data
- GTIN : 00621037092914
- Weight : 15
