JDC3090 - Eaton Series C J-Frame Molded Case Circuit Breaker 3-Pole 90A 600V

JDC3090

JDC3090 is an Eaton Series C complete molded case circuit breaker designed for industrial and commercial power distribution applications. This J-frame breaker features fixed thermal and fixed magnetic trip protection with three poles rated at 90 amperes and 600 Vac / 250 Vdc voltage ratings. The JDC3090 delivers an interrupting capacity of 200 kAIC at 240 Vac, 100 kAIC at 480 Vac, and 50 kAIC at 600 Vac, making it suitable for demanding electrical systems. It operates at 50/60 Hz frequency and comes factory assembled as a complete breaker with line and load terminals for convenient installation. The unit is UL Listed and meets industry standards for safety and performance. Dimensions are approximately 10.49 cm wide by 25.40 cm high by 10.31 cm deep, with a weight of 6.46 kg.

• Catalog Number: JDC3090
• Manufacturer: Eaton Cutler-Hammer
• Series: C
• Frame Type: J-Frame
• Circuit Breaker Type: JDC
• Number of Poles: 3
• Amperage Rating: 90 A
• Voltage Rating: 600 Vac, 250 Vdc
• Trip Type: Fixed thermal, fixed magnetic
• Interrupting Capacity: 200 kAIC at 240 Vac, 100 kAIC at 480 Vac, 50 kAIC at 600 Vac
• Frequency: 50/60 Hz
• Certifications: UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: JDC3090
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : JDC
• Voltage : 600
• Amperage : 90
• Phase : 3
• Poles : 3
• AIC rating : 100kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : J Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786679026670
• GTIN : 00786679026670
• Country of Origin : Dominican Republic
• Dimensions : 4.06 in x 10 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 14.25
• Certification : UL Listed
