Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
JDB3250X
JDB3250X is a 250 Amp, 600 VAC, 3-pole molded case circuit breaker from Eaton's Series C J-frame lineup with fixed thermal and fixed magnetic trip units.
This complete breaker features a JDB type frame designed for load-side aluminum terminals, suitable for 50/60 Hz applications. It offers a high interrupt rating of 65 kAIC at 240 VAC and 35 kAIC at 480 VAC, ensuring reliable protection in demanding electrical environments. The breaker is UL Listed and factory sealed for quality assurance.
- Amperage Rating: 250 A
- Voltage Rating: 600 VAC, 250 VDC
- Number of Poles: Three-pole
- Frame: J (JDB type)
- Series: Series C
- Trip Type: Fixed thermal, fixed magnetic
- Interrupt Rating: 65 kAIC at 240 VAC, 35 kAIC at 480 VAC
- Terminal Material: Aluminum
- Frequency Rating: 50 to 60 Hz
- Circuit Breaker Type: Complete breaker
- Certifications: UL Listed
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: JDB3250X
- Manufacturer : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : JDB
- Voltage : 600
- Amperage : 250
- Phase : 3
- Poles : 3
- AIC rating : 35kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : J Frame
- Protection : Thermal Magnetic
Product Data
- UPC : 782114740538
- GTIN : 00782114740538
- Country of Origin : Dominican Republic
- Dimensions : 4.06 in x 4.13 in x 4.13 in (Length/Depth x Height x Width)
- Weight : 11.25
- Certification : UL Listed
