JDB3100W - Eaton 100A 600V 3-Pole J-Frame Series C Molded Case Circuit Breaker

JDB3100W

JDB3100W is a 100 amp, 600 volt, 3-pole molded case circuit breaker from Eaton's Series C J-Frame line designed for reliable circuit protection.This Eaton JDB3100W breaker features a fixed thermal and magnetic trip unit (T186), suitable for 600 VAC and 250 VDC applications. It offers a 3-pole configuration with a J-frame design, providing a 65 kA interrupt rating at 240 VAC and 35 kA at 480 VAC, ensuring high interrupting capacity for demanding electrical environments.

Key Specifications
• Amperage: 100 A
• Voltage Rating: 600 VAC / 250 VDC
• Poles: 3
• Frame Type: J-Frame
• Series: Eaton Series C
• Trip Unit: Fixed Thermal / Magnetic (T186)
• Interrupt Rating: 65 kA at 240 VAC, 35 kA at 480 VAC
• Mounting Type: Fixed
• Certifications: Eaton standard industrial certifications
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Additional Information

Lugs are not included




Specifications

• Part Number: JDB3100W
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : JDB
• Voltage : 600
• Amperage : 100
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : J Frame
• Protection : Thermal Magnetic



Product Data

• UPC : 786679516232
• GTIN : 00786679516232
• Country of Origin : Dominican Republic
• Dimensions : 4.06 in x 10 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 11.25
• Certification : UL Listed
