Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
JDB3090W
JDB3090W is an Eaton Series C complete molded case circuit breaker designed for reliable power distribution and circuit protection in industrial and commercial applications. This J-frame breaker features fixed thermal and fixed magnetic trip technology for dependable overcurrent protection across a wide range of electrical systems.
- Amperage Rating: 90A
- Voltage Rating: 600 Vac, 250 Vdc
- Number of Poles: Three-pole
- Frame Type: J-frame
- Circuit Breaker Type: JDB Complete breaker
- Trip Type: Fixed thermal, fixed magnetic
- Interrupt Rating: 65 kAIC at 240 Vac, 35 kAIC at 480 Vac
- Frequency Rating: 50/60 Hz
- Certifications: UL Listed
- Series: Series C
- Dimensions: 10 in height, 4.13 in width, 4.06 in depth
- Weight: 11 lb
Additional Information
This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.
Specifications
- Part Number: JDB3090W
- Manufacturer : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : JDB
- Voltage : 600
- Amperage : 90
- Phase : 3
- Poles : 3
- AIC rating : 35kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : J Frame
- Protection : Thermal Magnetic
Product Data
- UPC : 786679516218
- GTIN : 00786679516218
- Country of Origin : Dominican Republic
- Dimensions : 4.06 in x 10 in x 4.13 in (Length/Depth x Height x Width)
- Weight : 11.25
- Certification : UL Listed
