Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Molded Case
Description
JDB2200
JDB2200 is a Cutler Hammer 2-pole molded case circuit breaker rated for 200 amps and 600 volts with a 35kA interrupting rating.
This circuit breaker features a feed-thru connection type and fixed thermal/magnetic trip unit, designed for reliable protection in industrial and commercial power distribution applications. It fits the J frame series and supports both 600 Vac and 250 Vdc voltage ratings.
- Key Specifications
- Amperage: 200 A
- Voltage: 600 Vac, 250 Vdc
- Poles: 2
- Interrupt Rating: 35kA @ 480V
- Frame: J
- Trip Type: Fixed Thermal/Magnetic
- Connection Type: Feed-Thru
- Certifications: Eaton Cutler Hammer standard
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: JDB2200
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : JDB
- Voltage : 600
- Amperage : 200
- Phase : 1
- Poles : 2
- AIC rating : 35kA@480V
- Connection : Feed-Thru
- Functions : Long Time and Instantaneous Trip
- Frame Size : J Frame
- Temp Rating : -13–158 °F (-25–70 °C)
- Protection : Thermal Magnetic
Product Data
- UPC : 786679516126
- GTIN : 00786679516126
- Country of Origin : Dominican Republic
- Dimensions : 4.06 in x 4.13 in x 4.13 in (Length/Depth x Height x Width)
- Weight : 1
- Certification : UL Listed
