Product Info
- Manufacturer:Eaton
- Sub-Category:Breaker Type
Description
IBPED3020
IBPED3020 is an Eaton Pow-R-Way III circuit breaker plug-in unit designed for busway power distribution systems. This three-pole breaker-type bus plug delivers reliable performance in 240V applications with a 20A amperage rating and 65 kAIC interrupt capacity at 240 Vac. The unit features an E-frame design with integral housing ground path and is certified to meet NEMA and UL 857 standards for safe, code-compliant installation.The IBPED3020 combines robust construction with proven Pow-R-Way III technology, offering finger-safe plug-in connections and a two-piece extruded aluminum housing. This breaker plug integrates seamlessly into existing Pow-R-Way III busway systems and is suitable for industrial and commercial power distribution applications requiring compact, efficient load takeoff points.
- Amperage Rating: 20A
- Voltage Rating: 240V
- Number of Poles: Three-pole
- Circuit Breaker Frame: E
- Interrupt Rating: 65 kAIC at 240 Vac
- Design Series: Pow-R-Way III
- Mounting Type: Plug-in
- Certifications: UL 857, NEMA Compliant, CSA Certified
- Grounding: 50% Integral/Housing
- Product Weight: 25 lb
Specifications
- Part Number: IBPED3020
- Manufacturer : Eaton
- Category : Bus Plug
- Item Subcategory : Breaker Type
- Family : POW-R-WAY I And II
- Type : IBPED
- Voltage : 240
- Amperage : 20
- Phase : 3
- AIC rating : 65kA@240V
- Wire : 3
- Compatible Frames : ED
Product Data
- Weight : 40
