HU463 - Square D 100A 600V 4-Pole Heavy Duty Safety Switch NEMA 1 Non-Fusible

HU463

HU463 is a Square D heavy duty safety switch rated for 100 amps and 600 volts AC/DC with 4 poles and a NEMA 1 enclosure.HU463 features a single throw handle actuator with visible blades for positive off indication, quick-make/quick-break mechanism, and a dual cover interlock for safety. It supports a 200kA interrupt rating at 600V and is constructed with a painted steel enclosure. The switch includes provisions for handle lock-off and padlocking the cover, making it suitable for industrial applications requiring reliable disconnect and safety compliance.

Key Specifications
• Amperage: 100 A
• Voltage: 600 VAC/DC
• Poles: 4
• Enclosure Type: NEMA 1 Painted Steel
• Interrupt Rating: 200kA at 600V
• Actuator Type: Handle/Single Throw
• Non-Fusible Design
• Dimensions: 16.13 in W x 6.85 in D x 20.5 in H
• Dual Cover Interlock for Safety
• Handle Lock-Off Provision
• UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HU463
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Switch
• Item Subcategory : Disconnect
• Family : Series E
• Type : HU
• Voltage : 600 AC/DC
• Amperage : 100
• Phase : 3
• Poles : 4
• AIC rating : 200kA@600V
• Configuration : Single
• Switch Style : Non-Fusible
• Nema Rating : NEMA 1
• Compatible Frames : ED

Product Data

• UPC : 78590150593
• GTIN : 00785901505938
• Country of Origin : United States
• Dimensions : 20.5 in (520.7 mm) x 16.13 in (409.70 mm) x 6.85 in (173.99 mm) (Height x Width x Depth)
• Weight : 28.909
• Certification : UL listed
