HMD63B700H
HMD63B700H is a Siemens 700 amp, 600 volt, 3 pole molded case circuit breaker designed for reliable power distribution protection.This circuit breaker is part of the Siemens Sentron Series with an ND frame, suitable for low voltage applications. It features a 65 kiloampere interrupting rating at 480 VAC and 50 kiloampere at 600 VAC, meeting UL 489 and IEC 60947-2 standards. The breaker is rated for operation at 40 degrees Celsius and supports both AC and DC voltages up to 600 VAC and 500 VDC.
- Key Specifications
- Amperage: 700 A
- Voltage: 600 VAC / 500 VDC
- Poles: 3
- Frame Type: ND Frame (HMD Series)
- Interrupting Rating: 65 kA at 480 VAC, 50 kA at 600 VAC
- Standards: UL 489, IEC 60947-2
- Trip Unit: Thermal Magnetic
- Mounting Type: Feed-Thru
- Part Number: HMD63B700H
- Manufacturer : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Sentron Series
- Type : HMD
- Voltage : 600
- Amperage : 700
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : MD Frame
- Protection : Thermal Magnetic
- UPC : 078364321493
- GTIN : 00783643214934
- Weight : 65
