Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
HMD63B700
HMD63B700 is a Siemens 3 pole thermal magnetic molded case circuit breaker rated for 700 amps and 600 volts.This Siemens HMD63B700 circuit breaker features a 3-pole configuration with a 700 ampere current rating and 600 volt AC voltage rating. It belongs to the MD frame series with a thermal magnetic trip unit and a high interrupting capacity of up to 50kA at 600V. The breaker is designed for surface mounting with a NEMA Type 1 enclosure and is interchangeable with other trip units in the MD frame family. It is suitable for low voltage power distribution applications and complies with industry certifications.
- Key Specifications
- Manufacturer: Siemens
- Part Number: HMD63B700
- Amperage: 700 Amps
- Voltage Rating: 600 VAC / 500 VDC
- Poles: 3
- Interrupt Rating: 50kA @ 600V
- Frame/Series: MD Frame (HMD6)
- Trip Unit: Thermal Magnetic
- Mounting Type: Surface Mount, NEMA Type 1 Enclosure
- Temperature Rating: Standard 40°C
- Certifications: Industry Standard Compliance
- Part Number: HMD63B700
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Sentron Series
- Type : HMD
- Voltage : 600
- Amperage : 700
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : MD Frame
- Protection : Thermal Magnetic
- UPC : 783643214767
- GTIN : 00783643214767
- Country of Origin : Mexico
- Weight : 57.871
