Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
HMD63B500
HMD63B500 is a Siemens 3 pole molded case circuit breaker rated for 500 amps and 600 volts AC, designed for reliable power distribution protection.This Siemens HMD63B500 circuit breaker features a thermal magnetic trip unit within the MD frame series, providing a high interrupt rating of 50kA at 600V. It is surface mounted with a NEMA Type 1 enclosure and meets UL 489 and IEC 60947-2 standards for safety and performance. The breaker supports interchangeable trip units and is suitable for industrial and commercial applications requiring robust circuit protection.
- Amperage: 500A
- Voltage: 600VAC
- Poles: 3
- Frame Type: HMD (MD Frame)
- Interrupt Rating: 50kA at 600V
- Trip Unit: Thermal Magnetic
- Mounting Type: Surface Mount, NEMA Type 1 Enclosure
- Standards: UL 489, IEC 60947-2
- Series: Sentron MD6 / MXD6
- Mechanical Trip
- High Breaking Capacity
Specifications
- Part Number: HMD63B500
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Sentron Series
- Type : HMD
- Voltage : 600
- Amperage : 500
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Feed-Thru
- Functions : Long Time and Instantaneous Trip
- Frame Size : MD Frame
- Temp Rating : -13–158 °F (-25–70 °C)
- Protection : Thermal Magnetic
Product Data
- UPC : 783643214743
- GTIN : 00783643214743
- Country of Origin : Mexico
- Weight : 57.475
- Wire Size : 1/0 AWG to 500 KCM CU/AL
