HMCPS100R3C - Cutler Hammer 100A 600V 3-Pole Motor Circuit Protector, Series C Frame J-K

HMCPS100R3C

HMCPS100R3C is a 100 amp, 600 volt, 3-pole motor circuit protector from Cutler Hammer, designed for reliable motor protection in industrial applications.HMCPS100R3C features a Series C frame J-K motor circuit breaker with adjustable trip settings ranging from 23 to 84.5 full load amps, magnetic trip range 300-1000 A, and non-aluminum terminals. It complies with UL 489 standards and is UL Listed, CSA Certified, and CE approved for safety and performance. The breaker is panel mountable and suitable for use in NEMA 3 starter applications.

• Amperage: 100 A
• Voltage Rating: 600 VAC / 250 VDC
• Poles: 3
• Frame: Series C, Frame J-K
• Trip Unit: Adjustable motor circuit protector, 23-84.5 FLA
• Interrupt Rating: Per UL 489 standards
• Mounting Type: Panel mount
• Terminal Material: Non-aluminum
• Certifications: UL Listed, CSA Certified, CE Approved
• Weight: Approximately 4.5 lbs
• Dimensions: 5" H x 5" W x 8" D

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HMCPS100R3C
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : HMCPS
• Voltage : 600
• Amperage : 100
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Feed-Thru
• Functions : I - Instantaneous
• Frame Size : F Frame
• Protection : Magnetic Only

Product Data

• UPC : 786679232668
• GTIN : 00786679232668
• Country of Origin : Dominican Republic
• Dimensions : 7.25 in x 5 in x 5 in (Length/Depth x Height x Width)
• Weight : 4.5
• Certification : CSA Certified,UL Listed
