HMCPS003A0C - Cutler Hammer 3A 600V 3-Pole Molded Case Circuit Breaker, Magnetic Trip, HMCPS Frame, Motor Protection

HMCPS003A0C

HMCPS003A0C is a Cutler Hammer 3-pole molded case circuit breaker designed for motor protection applications.

This magnetic trip circuit breaker features a 3A current rating, 600V voltage rating, and is built on the HMCPS frame. It is engineered for use with electric starters and provides reliable circuit protection in industrial environments. The breaker is suitable for installations requiring a compact, durable solution with a magnetic trip unit for fast response to overloads and short circuits.

Key Specifications

• Part Number: HMCPS003A0C
• Manufacturer: Cutler Hammer
• Amperage: 3A
• Voltage: 600V
• Poles: 3
• Mounting Type: Panel or enclosure (standard molded case)
• Interrupt Rating: Not specified in available data
• Series/Frame: HMCPS (Frame J-K, Series C)
• Trip Unit: Magnetic
• Certifications: Not specified in available data
• Application: Motor circuit protector, electric starters
• Dimensions: 4.8" x 5.1" x 7.6" (approximate)
• Weight: 4.55 lbs (approximate)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HMCPS003A0C
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : HMCPS
• Voltage : 600
• Amperage : 3
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : I - Instantaneous
• Terminal Connection : Line/Load Lug
• Frame Size : 250A/J
• Temp Rating : Minimum Operating Temp -4 Degrees F Max. Operating Temp.158 Degrees F
• MCM Size : Min. Wire Size 14 AWG Max. Wire Size 1/0 AWG
• Breaker Type : Standard
• Protection : Magnetic Only
• Phase Connection : ABC

Product Data

• UPC : 786679804247
• GTIN : 00786679804247
• Country of Origin : Dominican Republic
• Dimensions : 7.6 in x 4.8 in x 5.1 in (Length/Depth x Height x Width)
• Weight : 4.55
• Panel Type : Motor Starters Equipped with Electronic Overload Relays
• Standards : CSA Certified, IEC Rated, UL Listed
• Certification : CSA Certified, IEC Rated, UL Listed
