Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
HMCP070M2S04
HMCP070M2S04 is a 70 Amp, 3-pole motor circuit protector from Eaton designed for motor protection applications.
This motor circuit protector features a magnetic-only trip type with a trip range of 210 to 700 Amps. It is part of Eaton's Series C, Frame J-K, and supports voltage ratings of 600 VAC and 250 VDC. The device is panel mountable and uses non-aluminum terminals. It is UL Listed and CSA Certified for safety and compliance.
- Amperage Rating: 70A
- Voltage Rating: 600 VAC, 250 VDC
- Number of Poles: 3
- Trip Type: Magnetic only
- Trip Range: 210-700 A
- Series: Series C
- Frame Size: J-K
- Mounting Type: Panel mount
- Terminal Material: Non-aluminum
- Certifications: UL Listed, CSA Certified
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Additional Information
complete with left-pole mounted 12-24Vac/dc terminal block left side shunt trip
Specifications
- Part Number: HMCP070M2S04
- Manufacturer : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : HMCP
- Voltage : 600
- Amperage : 70
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Feed-Thru
- Functions : I - Instantaneous
- Frame Size : F Frame
- Protection : Magnetic Only
Product Data
- Weight : 5
