HMCP070M2C - Cutler Hammer 70 Amp 3 Pole Motor Circuit Protector, Frame J-K, Series C

HMCP070M2C

HMCP070M2C is a Cutler Hammer motor circuit protector designed for reliable motor protection in industrial applications.This molded case circuit breaker features a 70 Amp rating with three poles, suitable for 600 VAC operation. It belongs to the Series C family with a Frame J-K size and offers magnetic trip protection in the 210-700 Amp range. The device is UL Listed and CSA Certified, constructed with non-aluminum terminals for durability.

• Manufacturer: Cutler Hammer (Eaton)
• Part Number: HMCP070M2C
• Amperage: 70A
• Poles: 3
• Voltage Rating: 600 VAC
• Frame Size: J-K
• Series: C
• Trip Unit: Magnetic (210-700 A)
• Mounting Type: Panel Mount
• Terminal Material: Non-aluminum
• Certifications: UL Listed, CSA Certified

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HMCP070M2C
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : HMCP
• Voltage : 600
• Amperage : 70
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : Instantaneous
• Terminal Connection : Line/Load Lug
• Frame Size : 250A/J
• Temp Rating : Minimum Operating Temp -4 Degrees F Max. Operating Temp.158 Degrees F
• MCM Size : Min. Wire Size 14 AWG Max. Wire Size 1/0 AWG
• Breaker Type : Standard
• Protection : Magnetic Only
• Phase Connection : ABC

Product Data

• UPC : 786679150849
• GTIN : 00786679150849
• Country of Origin : Dominican Republic
• Dimensions : 7.7 in x 4.9 in x 4.9 in (Length/Depth x Height x Width)
• Weight : 4.5
• Panel Type : Eaton Motor Starters, Rockwell Motor Starters
• Standards : CSA Certified, IEC Rated, UL Listed
• Certification : CSA Certified, IEC Rated, UL Listed
