HMCP003A0C - Cutler Hammer 3A 600V 3 Pole F Frame Magnetic Motor Circuit Protector, Series C, Instantaneous Trip, UL/CSA Certified

HMCP003A0C

HMCP003A0C is a Cutler Hammer 3A, 3 pole, 600V magnetic motor circuit protector designed for reliable motor circuit protection.

This Eaton/Cutler-Hammer molded case circuit breaker features a non-interchangeable, instantaneous-only magnetic trip unit, F frame style, and is rated for 600VAC/250VDC applications. It is ideal for protecting motors with full load currents between 0.69 and 2.5A, and offers a feed-thru connection type with non-aluminum terminals. The breaker is UL Listed and CSA Certified for safety and compliance.

Key Specifications
• Part Number: HMCP003A0C
• Manufacturer: Cutler Hammer (Eaton)
• Amperage: 3A
• Voltage: 600VAC, 250VDC
• Poles: 3
• Mounting Type: Bolt On (Feed-Thru)
• Interrupt Rating: 65kA @ 480V
• Series/Frame: Series C, F Frame
• Trip Unit: Magnetic, Instantaneous-only, non-interchangeable, 9-30A adjustable
• Motor FLA Range: 0.69-2.5A
• Certifications: UL Listed, CSA Certified
• Terminal Material: Non-aluminum
• NEMA Starter Size: 0

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HMCP003A0C
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : HMCP
• Voltage : 600
• Amperage : 3
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Feed-Thru
• Functions : I - Instantaneous
• Terminal Connection : Line/Load Lug
• Frame Size : 250A/J
• Temp Rating : Minimum Operating Temp -4 Degrees F Max. Operating Temp.158 Degrees F
• MCM Size : Min. Wire Size 14 AWG Max. Wire Size 1/0 AWG
• Breaker Type : Standard
• Protection : Magnetic Only
• Phase Connection : ABC

Product Data

• UPC : 786679150795
• GTIN : 00786679150795
• Country of Origin : Dominican Republic
• Dimensions : 8 in x 5 in x 5 in (Length/Depth x Height x Width)
• Weight : 4.5
• Panel Type : Eaton Motor Starters, Rockwell Motor Starters
• Standards : CSA Certified, IEC Rated, UL Listed
• Certification : CSA Certified, IEC Rated, UL Listed
