HJXD63B200H - Siemens 200A 600V 3-Pole FD Frame Thermal Magnetic Circuit Breaker Bolt-On

HJXD63B200H

HJXD63B200H is a Siemens 3-pole, 200 amp thermal magnetic molded case circuit breaker designed for industrial and commercial power distribution applications.This Siemens HJXD63B200H circuit breaker features a 600 VAC voltage rating and a 22 kA interrupt rating. It is built on the FD frame and includes a thermal magnetic trip unit with a trip range of 900 to 2000 amps. The breaker is bolt-on mounted and UL 489 listed with HACR rating, suitable for motor circuit protection and short circuit interruption. It supports line/load lug connections and is rated for use at 40 degrees Celsius ambient temperature.

Key Specifications
• Manufacturer: Siemens
• Part Number: HJXD63B200H
• Amperage: 200 A
• Voltage Rating: 600 VAC
• Number of Poles: 3
• Frame: FD
• Interrupt Rating: 22 kA
• Trip Unit: Thermal Magnetic
• Mounting Type: Bolt-On
• Approvals: UL 489 Listed, HACR Rated
• Phase: 3
• Operating Temperature: 40°C
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Additional Information

This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.




Specifications

• Part Number: HJXD63B200H
• Manufacturer : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Sentron Series
• Type : HJXD
• Voltage : 600
• Amperage : 200
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : JD Frame
• Protection : Thermal Magnetic



Product Data

• UPC : 783643320093
• GTIN : 00783643320093
• Country of Origin : Mexico
• Weight : 15.801
