HJP36080 - Square D PowerPact H Molded Case Circuit Breaker 80A 600V 3P Unit Mount Thermal Magnetic

HJP36080

HJP36080 is a Square D PowerPact H molded case circuit breaker designed for reliable protection in industrial and commercial power distribution systems. This 3-pole breaker features a thermal magnetic trip unit and is rated for 80A continuous current at up to 600VAC, making it suitable for a wide range of applications requiring dependable circuit protection. The HJP36080 is built with a robust H-frame construction and is designed for unit mount installation, providing flexibility for various panel configurations. It offers a breaking capacity of 25kA at 600VAC and is equipped with a thermal magnetic trip unit for both overload and short-circuit protection. The breaker is UL 489 listed and meets multiple international standards for safety and performance.

• Part Number: HJP36080
• Manufacturer: Square D
• Series: PowerPact H
• Frame Type: H-Frame
• Amperage: 80A
• Voltage: 600VAC
• Poles: 3
• Mounting Type: Unit Mount
• Interrupt Rating: 25kA at 600VAC
• Breaker Type: Molded Case
• Protection Type: Thermal Magnetic
• Certifications: UL 489 Listed, CCC, IEC, CE, CSA

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HJP36080
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HJP
• Voltage : 600
• Amperage : 80
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Lug, Terminal Nut
• Frame Size : H
• Temp Rating : 28-158 °F (-2-70 °C)
• MCM Size : Min. Wire Size 14 AWG (Cu/Al) Max. Wire Size 3/0 AWG (Cu/Al)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901564461
• GTIN : 00785901564461
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 4.9
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
