HJL36090SA - Square D 90 Amp 3 Pole H Frame Molded Case Circuit Breaker 600VAC 65kA Interrupt Rating

HJL36090SA

HJL36090SA is a Square D 90 Amp 3 Pole H Frame molded case circuit breaker designed for reliable power distribution protection.

This circuit breaker features a thermal magnetic trip unit and is rated for up to 600 VAC and 250 VDC operation. It has a 3-pole configuration with a 65kA interrupt rating at 480 VAC (J Interrupt Code) and is UL 489 listed with multiple global certifications including CSA, NEMA, IEC, and CE marking. The breaker is unit mount type with line and load lugs and is part of the PowerPacT H series, offering easy installation and versatile terminal options.

• Amperage: 90 Amp
• Voltage Rating: 600 VAC / 250 VDC
• Poles: 3 Pole
• Frame Type: H Frame Molded Case
• Interrupt Rating: 65kA at 480 VAC (J Code)
• Trip Unit: Thermal Magnetic
• Mounting Type: Unit Mount
• Certifications: UL 489, CSA, NEMA, IEC, CE
• Series: PowerPacT H
• Terminal Options: Line and Load Lugs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

complete with 110/130Vac shunt trip

Specifications

• Part Number: HJL36090SA
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HJL
• Voltage : 600
• Amperage : 90
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : H Frame
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901533962
• GTIN : 00785901533962
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 5
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
