Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
HJL36030AABC
HJL36030AABC is a 30 Amp, 3-pole, 600 Volt molded case circuit breaker from Square D's Powerpact H-Frame series featuring thermal magnetic trip technology.This breaker offers a feed-thru connection with long-time and instantaneous trip functions, designed for unit mount lug installation and suitable for reverse fed applications.
- Manufacturer: Square D
- Frame Type: H-Frame
- Amperage: 30 Amp
- Poles: 3
- Voltage Rating: 600 Volt
- Interrupt Rating: 65kA at 480V, 25kA at 600V
- Trip Unit: Thermal Magnetic (Long-Time and Instantaneous)
- Mounting Type: Unit Mount Lug
- Connection Type: Feed-Thru, Line and Load Side Lugs
- UL Listed
- Dimensions (HxWxD): 6.4" x 4.12" x 4.36"
Specifications
- Part Number: HJL36030AABC
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Voltage : 600
- Amperage : 30
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
- Weight : 5
- Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
- Certification : UL, CSA, NOM
- Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
