Product Info
- Manufacturer:Square D
- Sub-Category:Molded Case
Description
HJF36090
HJF36090 is a Square D PowerPacT H-frame molded case circuit breaker rated for 90 amperes at 600 volts AC, three pole configuration designed for unit mount installation. This thermal-magnetic trip unit breaker provides reliable overload and short-circuit protection for industrial and commercial electrical systems. Key Specifications
- Amperage: 90 Amp
- Voltage: 600 VAC
- Poles: 3 Pole
- Frame Type: H-Frame
- Mounting: Unit Mount
- Trip Unit: Thermal-Magnetic
- Interrupt Rating: 25 kA at 480 VAC, 18 kA at 600 VAC
- UL 489 Listed
- CSA, NEMA, IEC certified
Additional Information
This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.
Specifications
- Part Number: HJF36090
- Manufacturer : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Powerpact
- Type : HJF
- Voltage : 600
- Amperage : 90
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : H Frame
- Protection : Thermal Magnetic
Product Data
- Weight : 5
