Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
HJF36045
HJF36045 is a Schneider Electric PowerPact H circuit breaker designed for reliable thermal magnetic protection in electrical distribution systems.This 45 amp, 3 pole circuit breaker operates at 600 volts AC and features a 25 kiloamp interrupt rating, providing robust short circuit protection. It has an 80% continuous current rating and is part of the PowerPact H frame series, known for its durability and compatibility with various mounting types including unit mount and I-line constructions. The breaker is UL 489 listed and meets multiple international certifications ensuring safety and performance.
- Amperage: 45A
- Voltage: 600VAC
- Poles: 3
- Interrupt Rating: 25kA
- Trip Unit: Thermal Magnetic
- Frame/Series: PowerPact H
- Continuous Current Rating: 80%
- Mounting Type: Unit mount, I-line compatible
- Certifications: UL 489, CSA, NEMA, IEC, CE
Additional Information
This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.
Specifications
- Part Number: HJF36045
- Manufacturer : Schneider Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Powerpact
- Type : HJF
- Voltage : 600
- Amperage : 45
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : H Frame
- Protection : Thermal Magnetic
Product Data
- Weight : 5
