HJA36070UN - Square D Powerpact H-Frame 70A 600V 3-Pole Molded Case Circuit Breaker I-Line Plug-In Thermal Magnetic

HJA36070UN

HJA36070UN is a Square D Powerpact H-Frame molded case circuit breaker designed for 3-pole, 70 ampere applications at 600 volts AC with I-Line plug-in mounting and thermal magnetic trip technology.This circuit breaker features a 70A continuous current rating with an 80% rating, suitable for 3-phase systems. It has a high interrupting capacity of up to 100kA at 240VAC, 65kA at 480VAC, and 25kA at 600VAC, providing robust protection. The breaker includes long-time and instantaneous trip functions with thermal magnetic trip units, an 800A magnetic hold current, and is UL listed for safety and reliability. It is designed for plug-in installation on I-Line panelboards and supports wire sizes from AWG 14 to 3/0 aluminum or copper.

• Manufacturer: Square D
• Part Number: HJA36070UN
• Frame Type: H-Frame
• Amperage: 70 A
• Voltage Rating: 600 VAC
• Number of Poles: 3
• Mounting Type: I-Line Plug-In
• Interrupt Rating: 100 kA @ 240 VAC, 65 kA @ 480 VAC, 25 kA @ 600 VAC
• Trip Unit: Thermal Magnetic (Long-Time and Instantaneous)
• Magnetic Hold Current: 800 A
• Wire Range: AWG 14 to 3/0 Aluminum/Copper
• Certifications: UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HJA36070UN
• Manufacturer : Square D
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HJA
• Voltage : 600
• Amperage : 70
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• Weight : 5
