HJA36020YP - Square D PowerPact H 20A 3 Pole 600V Molded Case Circuit Breaker I-Line Plug-In Mounting

HJA36020YP

HJA36020YP is a Square D PowerPact H molded case circuit breaker designed for reliable protection in commercial and industrial electrical systems. This 3-pole, 20A breaker features I-Line plug-in mounting and is built for use in 600V AC applications. The HJA36020YP utilizes a thermal magnetic trip unit for precise overload and short circuit protection. It is engineered for use in PowerPact H-frame switchgear and is suitable for a variety of demanding environments. The breaker is equipped with a padlock handle for added safety and operational control.

• Part Number: HJA36020YP
• Manufacturer: Square D
• Series/Frame: PowerPact H
• Amperage: 20A
• Poles: 3
• Voltage: 600V AC
• Mounting Type: I-Line Plug-In
• Interrupt Rating: 25kA @ 600V
• Interrupt Rating: 65kA @ 480V
• Interrupt Rating: 100kA @ 240V
• Phase: ABC
• Handle: Padlock Handle
• Trip Unit: Thermal Magnetic

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HJA36020YP
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HJA
• Voltage : 600
• Amperage : 20
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901950370
• GTIN : 00785901950370
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 5
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
