HJA260251 - Square D 25A 600V 2-Pole Molded Case Circuit Breaker Powerpact HJA Frame

HJA260251

HJA260251 is a 25 amp, 600 volt, 2-pole molded case circuit breaker from Square D's Powerpact HJA frame series.This circuit breaker features thermal magnetic trip units with long time and instantaneous trip functions, designed for I-Line plug-in mounting.

• Manufacturer: Square D
• Amperage: 25A
• Voltage: 600V AC
• Number of Poles: 2
• Frame Type: HJA (Powerpact)
• Trip Unit: Thermal Magnetic
• Interrupt Rating: 65kA at 480V AC
• Mounting Type: I-Line Plug-In
• Current Limiting
• Suitable for Reverse Fed Applications
• Phase Connection: A & B Phase

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HJA260251
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HJA
• Voltage : 600
• Amperage : 25
• Phase : 1
• Poles : 2
• AIC rating : 65kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Frame Size : H Frame
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901488712
• GTIN : 00785901488712
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 3.999
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
