HJA260152 - Square D 15A 600V 2 Pole Molded Case Circuit Breaker PowerPact H Frame

HJA260152

HJA260152 is a Square D 2 pole molded case circuit breaker rated for 15 amps and 600 volts, designed for reliable circuit protection in industrial applications.This thermal magnetic circuit breaker belongs to the PowerPact H frame series with a bolt-on mounting type. It features a 15 amp trip unit and an interrupt rating of up to 65kA at 480V AC, ensuring high fault current interruption capability. The breaker is UL listed, CSA certified, and IEC compliant for safety and performance.

• Amperage: 15 Amps
• Voltage: 600 Volts AC
• Poles: 2
• Mounting Type: Bolt-On
• Interrupt Rating: 65kA at 480V AC
• Series/Frame: PowerPact H
• Trip Unit: Thermal Magnetic
• Certifications: UL Listed, CSA Certified, IEC Compliant
• Type: Molded Case Circuit Breaker
• Manufacturer: Square D

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HJA260152
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HJA
• Voltage : 600
• Amperage : 15
• Phase : 1
• Poles : 2
• AIC rating : 65kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Frame Size : H Frame
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901601005
• GTIN : 00785901601005
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 5.28
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
