HHED63M050 - Siemens Sentron Series 50A 600VAC 3 Pole Molded Case Circuit Breaker Thermal Magnetic Trip

HHED63M050

HHED63M050 is a Siemens Sentron Series 3 pole molded case circuit breaker designed for reliable protection in commercial and industrial applications. This breaker features a 50A current rating, 600VAC voltage rating, and thermal magnetic trip technology for precise overcurrent protection. It is engineered for bolt-on mounting and offers a very high interrupting capacity, making it suitable for demanding environments including marine duty applications. The breaker is calibrated for long time and instantaneous trip functions, ensuring optimal performance and safety. This Siemens HHED63M050 circuit breaker is part of the Sentron Series, known for its robust construction and high reliability. It is designed for use in 3-phase systems and features load side lug terminals for easy installation. The breaker is rated for very high interrupting capacity and is suitable for applications requiring extra high short-circuit protection. Its thermal magnetic trip unit provides both overload and short-circuit protection, ensuring comprehensive circuit safety.

• Manufacturer: Siemens
• Part Number: HHED63M050
• Series/Frame: Sentron Series, HHED Frame
• Amperage: 50A
• Voltage Rating: 600VAC
• Poles: 3
• Mounting Type: Bolt-On
• Interrupt Rating: 65kAIC @ 480V
• Trip Unit: Thermal Magnetic
• Features: Long Time and Instantaneous Trip Functions
• Terminals: Load Side Lug
• Applications: Marine Duty Rated, 3 Phase Systems

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HHED63M050
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Sentron Series
• Type : HHED
• Voltage : 600
• Amperage : 50
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 783643007918
• GTIN : 00783643007918
• Country of Origin : Mexico
• Weight : 3.799
• Certification : UL, IEC
• Wire Size : AWG 10 to AWG 1/0, Cu/Al
