Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
HHED63M020
HHED63M020 is a Siemens 3-pole thermal magnetic molded case circuit breaker rated for 20 amps and 600 volts AC. It features a bolt-on mounting type and high interrupting capacity suitable for industrial applications.This Siemens HHED63M020 breaker is part of the HHED frame series, designed for reliable protection with long time and instantaneous trip functions. It has a 65kA interrupting rating at 480V, is marine duty rated, and includes load side lug terminals for secure connections.
- Amperage: 20 Amps
- Voltage: 600 VAC
- Number of Poles: 3
- Frame Type: HHED
- Mounting Type: Bolt-On
- Interrupt Rating: 65kA at 480V
- Trip Unit: Thermal Magnetic
- Certifications: Marine Duty Rated
- Load Side Lug Terminals
- Series: Sentron
- Calibrated for 50 Degree C Ambient
Specifications
- Part Number: HHED63M020
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Sentron Series
- Type : HHED
- Voltage : 600
- Amperage : 20
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Temp Rating : -13–158 °F (-25–70 °C)
- Protection : Thermal Magnetic
Product Data
- UPC : 783643007864
- GTIN : 00783643007864
- Country of Origin : Mexico
- Weight : 7
- Wire Size : 12 to 10 AWG (Aluminum), 14 to 10 AWG (Copper)
