HHED63M030 - Siemens 30A 600V 3 Pole Bolt-On Molded Case Circuit Breaker, 65kAIC@480V, Sentron Series, Thermal Magnetic Trip, ED Frame

HHED63M030

HHED63M030 is a Siemens 30A 600V 3 pole bolt-on molded case circuit breaker designed for demanding commercial and industrial applications.

This circuit breaker features a thermal magnetic trip unit for reliable overload and short-circuit protection, with an interrupting rating of 65kA at 480V and 18kA at 600V. It is part of the Sentron Series, ED frame, and is suitable for use in three-phase systems. The breaker includes load side lug terminals, is marine duty rated, and supports a wide wire range for flexible installation.

Key Specifications
• Manufacturer: Siemens
• Part Number: HHED63M030
• Amperage: 30A
• Voltage: 600V AC
• Poles: 3
• Mounting Type: Bolt-On
• Interrupt Rating: 65kAIC @ 480V, 18kAIC @ 600V
• Series/Frame: Sentron, ED Frame
• Trip Unit: Thermal Magnetic
• Certifications: Marine duty rated
• Wire Range: 10 - 1/0 AWG (Cu/Al)
• Maximum Operating Temperature: +40°C
• Actuator Type: Handle

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HHED63M030
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Sentron Series
• Type : HHED
• Voltage : 600
• Amperage : 30
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 783643007888
• GTIN : 00783643007888
• Country of Origin : Mexico
• Weight : 4.079
• Certification : Ul Listed
• Wire Size : AWG 10 to AWG 1/0, Cu/Al
