HGL36150M38X - Square D PowerPact H 150A 3 Pole 600V Molded Case Circuit Breaker

HGL36150M38X

HGL36150M38X is a Square D PowerPact H series molded case circuit breaker designed for reliable motor circuit protection and general power distribution applications. This 3 pole, 150 amp, 600V AC breaker features a Micrologic 2.2M trip unit for precise overload and phase unbalance protection. Engineered for durability and safety, it is suitable for surface mount or DIN rail installation. The HGL36150M38X offers robust performance with an interrupt rating of 18kA at 600V AC. It is part of the PowerPact H frame series and is ideal for industrial and commercial environments requiring dependable circuit protection. The breaker is equipped with lugs for secure wiring connections and is certified for use in a wide range of electrical systems.

• Part Number: HGL36150M38X
• Manufacturer: Square D
• Series/Frame: PowerPact H
• Amperage: 150A
• Voltage: 600V AC
• Number of Poles: 3
• Interrupt Rating: 18kA @ 600V AC
• Mounting Type: Surface Mount / DIN Rail
• Trip Unit: Micrologic 2.2M
• Actuator: Toggle
• Application: Motor Circuit Protection
• Certifications: UL Listed, CSA Certified

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HGL36150M38X
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Voltage : 600
• Amperage : 150
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Feed-Thru
• Functions : I - Instantaneous
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Magnetic Only

Product Data

• UPC : 078590194661
• Country of Origin : United States
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 5
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
