Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
HFD4150
HFD4150 is a Series C complete molded case circuit breaker from Eaton, designed for reliable protection in commercial and industrial power distribution systems.This four-pole circuit breaker features a fixed thermal and fixed magnetic trip unit, providing dependable overcurrent protection. It is rated for 150A continuous current and 600VAC maximum voltage, making it suitable for a wide range of applications. The breaker is UL Listed and built to Eaton's high standards for durability and safety.
- Amperage Rating: 150A
- Voltage Rating: 600VAC, 250VDC
- Number of Poles: 4
- Series/Frame: Series C, F-Frame
- Interrupt Rating: 65kAIC at 240VAC, 35kAIC at 480VAC
- Mounting Type: Complete breaker (fixed)
- Frequency Rating: 50/60 Hz
- Terminals: Line and load
- Trip Type: Fixed thermal, fixed magnetic
- Certifications: UL Listed
Specifications
- Part Number: HFD4150
- Manufacturer : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : HFD
- Voltage : 600 AC
- Amperage : 150
- Phase : 3
- Poles : 4
- AIC rating : 65kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- UPC : 786679253359
- GTIN : 00786679253359
- Country of Origin : Dominican Republic
- Dimensions : 3.38 in x 5.5 in x 5.5 in (Length/Depth x Height x Width)
- Weight : 4.5
- Certification : UL Listed
