Product Info
- Manufacturer:Westinghouse
- Sub-Category:Molded Case
Description
HFD4100L
HFD4100L is a Westinghouse 4-pole thermal magnetic circuit breaker rated for 100 amps and 600 volts AC, designed for reliable circuit protection in industrial and commercial applications.This circuit breaker is part of the Westinghouse F-Frame Series C family, featuring a thermal magnetic trip unit and a 4-pole configuration suitable for 3-phase, 4-wire systems. It offers a high interrupting capacity of 65,000 amperes at 600 volts AC, ensuring robust short-circuit protection. The breaker is designed for panel or enclosure mounting and is HACR rated, making it suitable for HVAC and other heavy-duty electrical equipment.
- Amperage: 100A
- Voltage Rating: 600V AC
- Number of Poles: 4
- Trip Unit: Thermal Magnetic
- Interrupting Rating: 65,000 AIC at 600V AC
- Frame Type: F-Frame (Series C)
- Mounting Type: Panel/Enclosure Mount
- HACR Rated
Specifications
- Part Number: HFD4100L
- Manufacturer : Westinghouse
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : HFD
- Voltage : 600 AC
- Amperage : 100
- Phase : 3
- Poles : 4
- AIC rating : 65kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- UPC : 786679271421
- GTIN : 00786679271421
- Country of Origin : Dominican Republic
- Dimensions : 3.38 in x 6 in x 5.5 in (Length/Depth x Height x Width)
- Weight : 4.5
- Certification : UL Listed
