HFD3080W - Eaton 3-Pole 80A 600V Molded Case Circuit Breaker Series C

HFD3080W

HFD3080W is an Eaton Series C complete molded case circuit breaker designed for industrial and commercial power distribution applications. This three-pole breaker features fixed thermal and fixed magnetic trip protection with a T186 trip unit, delivering reliable overcurrent and short-circuit protection in demanding environments.Key Specifications

• Amperage Rating: 80 A
• Voltage Rating: 600 Vac, 250 Vdc
• Number of Poles: Three-pole
• Circuit Breaker Type: HFD
• Series: Series C
• Frame: F-frame
• Trip Type: T186 (Fixed thermal, Fixed magnetic)
• Interrupt Rating: 100 kAIC at 240 Vac, 65 kAIC at 480 Vac
• Frequency Rating: 50/60 Hz
• Terminals: Load side, without terminals
• Certifications: UL Listed
• Warranty: One (1) year from installation or eighteen (18) months from shipment, whichever occurs first

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.

Specifications

• Part Number: HFD3080W
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : HFD
• Voltage : 600 AC
• Amperage : 80
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 782114983805
• GTIN : 00782114983805
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 4.5
• Certification : UL Listed
