HFD3015VSH09 - Cutler Hammer 15A 600V 3 Pole Molded Case Circuit Breaker Series C

HFD3015VSH09

HFD3015VSH09 is an Eaton Series C complete molded case circuit breaker rated for 15 amperes at 600 VAC or 250 VDC, designed for panel mounting in industrial and commercial power distribution applications.

This three-pole circuit breaker features fixed thermal and fixed magnetic trip protection with an F-frame design. The breaker delivers an interrupt rating of 100 kAIC at 240 VAC and 65 kAIC at 480 VAC, providing reliable overcurrent protection. Stainless steel load-side terminals ensure durability and corrosion resistance. The unit is calibrated at 50°C and rated for 50/60 Hz operation, making it suitable for diverse electrical systems.

• Amperage Rating: 15 A
• Voltage Rating: 600 VAC, 250 VDC
• Number of Poles: Three-pole
• Trip Type: Fixed thermal, fixed magnetic
• Interrupt Rating: 100 kAIC at 240 VAC; 65 kAIC at 480 VAC
• Frame Size: F-frame
• Series: Series C
• Mounting: Panel
• Terminal Material: Stainless steel
• Frequency Rating: 50/60 Hz
• Certification: UL 489
• Weight: 4.5 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HFD3015VSH09
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : HFD
• Voltage : 600 AC
• Amperage : 15
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F-Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786679030509
• GTIN : 00786679030509
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 4.5
• Certification : UL 489
