2 Year Warranty Guaranteed
All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.
Product Questions? Contact Us
Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
HFD2090LBP10
HFD2090LBP10 is a 90 amp, 2-pole molded case circuit breaker from Eaton's Series C F-frame line designed for reliable circuit protection.This breaker features a fixed thermal, fixed magnetic trip unit suitable for 600 Vac and 250 Vdc applications. It is a complete breaker with load side terminals, rated for 50/60 Hz operation. The HFD2090LBP10 offers an interrupt rating of 35 kAIC at 480 Vac and 65 kAIC at 240 Vac, ensuring robust fault current interruption. It is UL Listed and built to Eaton's high standards for industrial and commercial electrical systems.
- Key Specifications
- Amperage: 90 A
- Voltage Rating: 600 Vac, 250 Vdc
- Poles: 2
- Frame: F-Frame
- Series: Series C
- Trip Type: Fixed thermal, fixed magnetic
- Interrupt Rating: 35 kAIC at 480 Vac, 65 kAIC at 240 Vac
- Terminals: Load side
- Frequency: 50/60 Hz
- Certifications: UL Listed
- Part Number: HFD2090LBP10
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : HFD
- Voltage : 600 AC
- Amperage : 90
- Phase : 1
- Poles : 2
- AIC rating : 65kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
- Weight : 1
