Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
HFD2060BP10
HFD2060BP10 is a Westinghouse 60 amp, 2-pole circuit breaker designed for 600 volts AC applications with a fixed thermal and magnetic trip unit.This F-frame molded case circuit breaker provides reliable overload and short circuit protection with a high interrupting capacity suitable for industrial and commercial electrical systems. It features a bolt-on mounting type and is engineered to meet rigorous safety and performance standards.
- Amperage: 60 Amps
- Voltage Rating: 600 Volts AC
- Poles: 2
- Frame: F-Frame
- Trip Unit: Fixed Thermal Magnetic
- Interrupting Capacity: 65 kAIC at 480 VAC, 100 kAIC at 240 VAC
- Mounting Type: Bolt-On
- Standards: UL Listed
Specifications
- Part Number: HFD2060BP10
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : HFD
- Voltage : 600 AC
- Amperage : 60
- Phase : 1
- Poles : 2
- AIC rating : 65kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- Weight : 3
