Product Info
- Manufacturer:Siemens
- Sub-Category:Disconnect
Description
HF366N
HF366N is a Siemens Heavy Duty Fusible Safety Disconnect Switch designed for industrial and commercial power distribution applications. This switch provides reliable circuit isolation and protection for 3-phase systems with a solid neutral and fused configuration.Engineered for durability and safety, the HF366N features a visible blade design, load break capability, and padlock-off handle for added security. It is suitable for use in environments requiring a NEMA 1 enclosure and is rated for high short-circuit withstand capacity.
- 600 Ampere rating
- 600 Volt AC maximum
- 3 Pole, 3 Phase, 4 Wire
- NEMA 1 enclosure
- Heavy Duty construction
- Fusible type with Class R fuse compatibility
- 200kA short-circuit withstand rating at 600V
- Visible blade design
- Load break rated
- Padlock-off handle
- Solid neutral
Specifications
- Part Number: HF366N
- Manufacturer : Siemens
- Brand : Siemens
- Category : Switch
- Item Subcategory : Disconnect
- Section : Fusible Disconnect Switch
- Family : VBII Series
- Type : HF
- Voltage : 600 AC AC
- Amperage : 600
- Phase : 3
- Poles : 3
- AIC rating : 200kA@600V
- Temp Rating : -13ÁF - 158ÁF (-25ÁC - 70ÁC)
- Fuse Class : R
- Configuration : Single
- Switch Style : Fusible
- Nema Rating : NEMA 1
- Compatible Frames : PGP
Product Data
- UPC : 783643151130
- GTIN : 00783643152007
- Country of Origin : Mexico
- Dimensions : 29.921 x 60.63 x 12.992
- Weight : 171.365 lb
- Temp Rating : -13ÁF - 158ÁF (-25ÁC - 70ÁC)
- Certification : UL listed
