HDM36040 - Square D PowerPact H 3 Pole 40 Amp 600V Circuit Breaker Bolt-On Thermal Magnetic

HDM36040

HDM36040 is a Square D PowerPact H series 3 pole, 40 amp, 600V AC circuit breaker designed for reliable protection in commercial and industrial applications. This bolt-on breaker features thermal magnetic trip technology for precise overload and short-circuit protection. The HDM36040 is engineered for durability and safety, with a robust interrupting rating and compatibility with standard PowerPact H enclosures. It is suitable for use in a wide range of electrical distribution systems.

• Part Number: HDM36040
• Manufacturer: Square D
• Series/Frame: PowerPact H
• Poles: 3
• Rated Current: 40 Amps
• Rated Voltage: 600V AC
• Mounting Type: Bolt-On
• Protection Type: Thermal Magnetic
• Interrupting Rating: 14kA @ 600V AC
• Frame Size: H
• Trip Unit: LI (Long-Time and Instantaneous)
• Standards: UL 489, CSA C22.2 No. 5

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HDM36040
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HDM
• Voltage : 600
• Amperage : 40
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : H Frame
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 606486282185
• GTIN : 03606486282182
• Country of Origin : United States
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 5
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
