HDA36150U44X - Schneider Electric 150A 600V 3-Pole I-Line Style Circuit Breaker PowerPact H

HDA36150U44X

HDA36150U44X is a Schneider Electric 3-pole circuit breaker rated for 150 amps and 600 volts, designed with I-Line style plug-in mounting for PowerPact H series applications. This breaker features a 14kA interrupt rating at 600 VAC and includes a Micrologic 6.2A trip unit for reliable protection.The HDA36150U44X circuit breaker is engineered for industrial and commercial power distribution, providing robust performance with 80% rated main contacts and compatibility with standard I-Line panels. It supports three-phase systems and meets industry certifications for safety and durability.

Key Specifications
• Amperage: 150A
• Voltage: 600V
• Poles: 3
• Mounting Type: I-Line Style Plug-In
• Interrupt Rating: 14kA at 600 VAC
• Series/Frame: PowerPact H
• Trip Unit: Micrologic 6.2A
• Rated Main Contacts: 80%
• Phase: 3
• Certifications: Industry standard compliant
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: HDA36150U44X
• Manufacturer : Schneider Electric
• Brand : Schneider Electric
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HDA
• Voltage : 600
• Amperage : 150
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : I-Line Style Plug-In
• Functions : LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault
• Terminal Connection : I-Line, Lug
• Frame Size : H
• Temp Rating : 28-158 °F (-2-70 °C)
• MCM Size : Min. Wire Size 14 AWG (Cu/Al) Max. Wire Size 3/0 AWG (Cu/Al)
• Protection : Solid State
• Phase Connection : ABC



Product Data

• GTIN : 03606486282397
• Country of Origin : United States
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 8.001
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
