H60XFA1212 - Square D 60A 600VAC 3-Pole Heavy Duty Non-Fusible Auxiliary Safety Switch

H60XFA1212

H60XFA1212 is a Square D heavy duty non-fusible auxiliary safety switch rated for 60 amps and 600 VAC with 3 poles.

This switch features a 3-pole, single throw (3PST) design suitable for surface mounting with screw clamp terminals. It supports up to 250 VDC and is rated for 50 horsepower. The enclosure is cast aluminum with a NEMA 7/9 rating, making it suitable for hazardous indoor locations with exposure to damp heat. It has a short circuit rating of 10 kA and is UL listed and CSA certified. This Series E switch does not include an electrical interlock and is designed without a neutral wiring configuration.

Key Specifications
• Current Rating: 60 Amps
• Voltage Rating: 600 VAC / 250 VDC
• Poles: 3
• Switch Function: 3-Pole Single Throw (3PST)
• Mounting Type: Surface Mount
• Enclosure Material: Cast Aluminum
• NEMA Rating: 7/9
• Short Circuit Rating: 10 kA
• Horsepower Rating: 50 HP
• Electrical Connection: Screw Clamp Terminal
• Certifications: UL Listed, CSA Certified
• Series: Heavy Duty (Series E)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: H60XFA1212
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Switch
• Item Subcategory : Disconnect
• Family : Series E
• Type : H
• Voltage : 600
• Amperage : 60
• Phase : 3
• Poles : 3
• Configuration : Single
• Switch Style : Non-Fusible
• Nema Rating : 9-Jul
• Compatible Frames : ED

Product Data

• UPC : 785901083870
• GTIN : 00785901083870
• Dimensions : 15.93 in (404.62 mm) x 9.87 in (250.70 mm) x 6.96 in (176.78 mm) (Height x Width x Depth)
• Weight : 28.069
• Certification : UL LISTED, CSA APPROVED
