GHB3080S1 - Cutler Hammer 80A 480V 3-Pole Molded Case Circuit Breaker, Series C G-Frame

GHB3080S1

GHB3080S1 is a Cutler Hammer 3-pole molded case circuit breaker rated for 80 amps and 480 volts, designed for reliable circuit protection.This Eaton Series C G-frame circuit breaker features a thermal magnetic trip unit (T186) and is suitable for 480Y/277 VAC and 125/250 VDC applications. It provides a 14 kA interrupt rating at 480Y/277 VAC and 65 kA at 240 VAC, with a bolt-on mounting type and screw terminal connections.

Key Specifications
• Amperage: 80 A
• Voltage Rating: 480Y/277 VAC, 125/250 VDC
• Poles: 3
• Series/Frame: Series C G-Frame
• Trip Unit: Thermal Magnetic (T186)
• Interrupt Rating: 14 kA at 480Y/277 VAC, 65 kA at 240 VAC
• Mounting Type: Bolt-On
• Terminal Type: Screw Terminals
• Certifications: UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: GHB3080S1
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : GHB
• Voltage : 480
• Amperage : 80
• Phase : 3
• Poles : 3
• AIC rating : 14kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous Trip
• Terminal Connection : Screw Clamp
• Frame Size : 100/GHB
• Temp Rating : 28-158 ¡F (-2-70 ¡C)
• Breaker Type : Standard
• Protection : Thermal Magnetic

Product Data

• UPC : 786679029831
• GTIN : 00786679029831
• Country of Origin : Dominican Republic
• Dimensions : 2.63 in x 4 in x 3 in (Length/Depth x Height x Width)
• Weight : 1.7
• Panel Type : Eaton Powerline Panelboards
• Standards : UL 558
• Certification : CSA Certified, UL Listed
