GHB3015 Cutler-Hammer Molded Case Circuit Breaker 3-Pole 15A 480Y/277V G-Frame Bolt-On

GHB3015

GHB3015 Cutler-Hammer Molded Case Circuit Breaker 3-Pole 15A 480Y/277V G-Frame Bolt-On

The GHB3015 is a molded case circuit breaker rated 15A at 480Y/277VAC, listed to UL 489 standards for use in commercial panelboards and electrical assemblies. This G-frame thermal-magnetic circuit breaker features non-interchangeable trip units providing permanent long-time and instantaneous overcurrent protection. Engineered by Cutler-Hammer (Eaton), it operates efficiently at a 50/60 Hz frequency and carries a maximum DC rating of 125/250VDC.

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time. This bolt-on premium electrical component delivers a fixed 14 kAIC interrupting rating at 480Y/277VAC and 65 kAIC at 240VAC. It satisfies precise commercial bid submittals and engineering specifications, utilizing factory-installed standard load lugs rated for copper and aluminum conductors.

Common Applications

• Eaton Powerline commercial panelboard branch circuit protection.
• Industrial machinery electrical assemblies and EOEM integration.
• Commercial HVAC infrastructure and lighting distribution branch circuits.

Key Features

• Thermal-Magnetic Trip: Utilizes a calibrated bi-metal element for long-time overloads and a fixed magnetic coil for high-speed short-circuit clearing.
• Bolt-On Mounting: Heavy-duty bolt-on line tab mechanical connection ensures physical bus stability and reliable conductivity.
• Blow-Open Design: Features a high-speed contact separation configuration that limits downline thermal and mechanical stress.
• Three-Pole Configuration: Provides synchronized, simultaneous common-trip disconnection across all three phase conductors.

Specifications

• Amperage Rating: 15A
• Voltage Rating: 480Y/277VAC, 125/250VDC
• Number of Poles: 3-Pole
• Interrupt Rating: 14 kAIC at 480Y/277VAC, 65 kAIC at 240VAC
• Frame Size: G-Frame
• Trip Type: Fixed Thermal, Fixed Magnetic (LI)
• Terminal Connection: Standard Load Lugs (Aluminum/Copper Wire Rated)
• Wire Size Range: 14 to 10 AWG
• Frequency: 50/60 Hz
• Certifications: UL Listed, CSA Certified, Federal Specifications W-C375B

Product Identification

• Country of Origin: United States
• Dimensions: 4.0 in H x 3.0 in W x 2.63 in D
• Weight: 1.75 lb
• UPC/GTIN: 786679911259

FAQ

Q: What is the interrupting tier rating for the GHB3015 breaker? A: The GHB3015 breaker features an interrupting capacity tier of 14 kAIC at a maximum voltage of 480Y/277VAC and 65 kAIC at 240VAC.

Q: Does the GHB3015 feature an electronic or thermal-magnetic trip unit? A: This model features a non-interchangeable, fixe

Specifications

• Part Number: GHB3015
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : GHB
• Voltage : 480
• Amperage : 15
• Phase : 3
• Poles : 3
• AIC rating : 14kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous Trip
• Terminal Connection : Screw Clamp
• Frame Size : 100/GHB
• Temp Rating : 28-158 ¡F (-2-70 ¡C)
• MCM Size : Min. Wire Size 10 AWG Max. Wire Size 1/0 AWG
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Frequency : 50/60 Hz

Product Data

• UPC : 786679911259
• GTIN : 00786679911259
• Country of Origin : Dominican Republic
• Dimensions : 2.63 in x 4 in x 3 in (Length/Depth x Height x Width)
• Weight : 1.75 lb
• Panel Type : Eaton Powerline Panelboards
• Standards : UL 522
• Certification : CSA Certified, UL Listed
• Wire Size : 10 to 1/0 AWG
