GHB3015I - Eaton 15A 3-Pole Molded Case Circuit Breaker, 277V Max, G Frame, 3-Phase 4-Wire

GHB3015I

GHB3015I is a three-pole molded case circuit breaker designed for 3-phase, four-wire electrical systems. This Eaton circuit breaker provides reliable protection for branch circuits in commercial and industrial applications.Engineered with a G frame and thermal magnetic trip unit, the GHB3015I supports a maximum voltage of 277V AC and is suitable for use in distribution panels rated up to 480Y/277V. The breaker features a compact design for efficient panel space utilization and is built for durability in demanding environments.

• Part Number: GHB3015I
• Manufacturer: Eaton
• Amperage: 15A
• Number of Poles: 3
• Maximum Voltage: 277V AC
• Mounting Type: Panel Mount
• Frame: G Frame
• Series: GHB
• Trip Unit: Thermal Magnetic
• Application: 3-Phase, 4-Wire
• Compatible Voltage: 480Y/277V
• Frequency: 50/60 Hz

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: GHB3015I
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : GHB
• Voltage : 480
• Amperage : 15
• Phase : 3
• Poles : 3
• AIC rating : 14kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous Trip
• Terminal Connection : Screw Clamp
• Frame Size : 100/GHB
• Temp Rating : 28-158 ¡F (-2-70 ¡C)
• Breaker Type : Standard
• Protection : Thermal Magnetic

Product Data

• UPC : 782114312315
• GTIN : 00782114312315
• Country of Origin : Dominican Republic
• Dimensions : 2.875 in x 4 in x 3 in (Length/Depth x Height x Width)
• Weight : 1.45
• Panel Type : Eaton Powerline Panelboards
• Standards : UL 523
• Certification : CSA Certified, UL Listed
