GHB3060S1 - Westinghouse 60 Amp 3 Pole 480V Bolt-On Molded Case Circuit Breaker GHB Frame

Save $1,568.87
SKU: GHB3060S1-New
Condition: New
Price:
$992.11 $2,560.98
Stock:
Low inventory, please call for stock check
Factory Lead Time: 69 business days. Ships based on manufacturer availability when out of stock. All factory-ordered products are non-cancelable and non-returnable.

Same-Day Shipping

Most items ship same-day if ordered by 12:30 PM PST.

2 Year Warranty Guaranteed

All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.

Product Questions? Contact Us

Product Info

GHB3060S1 - Eaton/ Cutler Hammer/ Westinghouse Bolt-On 60 Amp 3 Pole Circuit Breaker - Essential Electric Supply
GHB3060S1 - Westinghouse 60 Amp 3 Pole 480V Bolt-On Molded Case Circuit Breaker GHB Frame - Essential Electric Supply
GHB3060S1 - Westinghouse 60 Amp 3 Pole 480V Bolt-On Molded Case Circuit Breaker GHB Frame - Essential Electric Supply
GHB3060S1 - Westinghouse 60 Amp 3 Pole 480V Bolt-On Molded Case Circuit Breaker GHB Frame - Essential Electric Supply
Roll over image to zoom in Click on image to zoom Images are for reference only
GHB3060S1 - Eaton/ Cutler Hammer/ Westinghouse Bolt-On 60 Amp 3 Pole Circuit Breaker - Essential Electric Supply
GHB3060S1 - Westinghouse 60 Amp 3 Pole 480V Bolt-On Molded Case Circuit Breaker GHB Frame - Essential Electric Supply
GHB3060S1 - Westinghouse 60 Amp 3 Pole 480V Bolt-On Molded Case Circuit Breaker GHB Frame - Essential Electric Supply
GHB3060S1 - Westinghouse 60 Amp 3 Pole 480V Bolt-On Molded Case Circuit Breaker GHB Frame - Essential Electric Supply

Description

GHB3060S1


GHB3060S1 is a 60 Amp, 3 Pole molded case circuit breaker from Westinghouse designed for reliable electrical protection in commercial and industrial applications.This Westinghouse GHB3060S1 circuit breaker features a bolt-on mounting type and a GHB series frame. It offers a 14kA interrupt rating at 480VAC and 65kA at 240VAC, with thermal magnetic trip units providing consistent overcurrent protection. Rated for 480V AC and 125/250V DC, it supports long-time and instantaneous trip functions and is suitable for reverse feed applications. The breaker is UL, CSA, NOM, and IEC certified.
    Key Specifications
    • Amperage: 60 Amps
    • Voltage: 480 VAC, 125/250 VDC
    • Poles: 3
    • Mounting Type: Bolt-On
    • Interrupt Rating: 14kA @ 480VAC, 65kA @ 240VAC
    • Series/Frame: GHB Frame
    • Trip Unit: Thermal Magnetic, Long-Time and Instantaneous
    • Certifications: UL, CSA, NOM, IEC
    • Suitable for Reverse Feed Applications
    • Non-Interchangeable Trip
At Essential Parts, we offer fast shipping, lowest price, and

Specifications

  • Part Number: GHB3060S1
  • Manufacturer : Eaton
  • Brand : Cutler Hammer
  • Category : Circuit Breaker
  • Item Subcategory : Molded Case
  • Family : Series C
  • Type : GHB
  • Voltage : 480
  • Amperage : 60
  • Phase : 3
  • Poles : 3
  • AIC rating : 14kA@480V
  • Connection : Bolt-On
  • Functions : LI - Long-Time and Instantaneous Trip
  • Terminal Connection : Screw Clamp
  • Frame Size : 100/GHB
  • Temp Rating : 28-158 ¡F (-2-70 ¡C)
  • Breaker Type : Standard
  • Protection : Thermal Magnetic

Product Data

  • UPC : 786679029800
  • GTIN : 00786679029800
  • Country of Origin : Dominican Republic
  • Dimensions : 2.63 in x 4 in x 3 in (Length/Depth x Height x Width)
  • Weight : 1.8
  • Panel Type : Eaton Powerline Panelboards
  • Standards : UL 553
  • Certification : CSA Certified, UL Listed

Accesories

Part Manufacture Sub Category
1288C75G03
1373D62G01
