GHB3040S1 - Eaton 40A 3-Pole Molded Case Circuit Breaker, 480Y/277VAC, 125/250VDC, 65kAIC, Series C, G-Frame, Thermal Magnetic Trip, Bolt-On, UL Listed

Save $1,568.87
SKU: GHB3040S1-New
Condition: New
Price:
$992.11 $2,560.98
Stock:
3 in stock
Limited availability — we'll confirm stock immediately after your order.

Same-Day Shipping

Most items ship same-day if ordered by 12:30 PM PST.

2 Year Warranty Guaranteed

All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.

Product Questions? Contact Us

Product Info

GHB3040S1 - Cutler Hammer/ Eaton/ Westinghouse Bolt-On 40 Amp 3 Pole Circuit Breaker - Essential Electric Supply
GHB3040S1 - Eaton 40A 3-Pole Molded Case Circuit Breaker, 480Y/277VAC, 125/250VDC, 65kAIC, Series C, G-Frame, Thermal Magnetic Trip, Bolt-On, UL Listed - Essential Electric Supply
GHB3040S1 - Eaton 40A 3-Pole Molded Case Circuit Breaker, 480Y/277VAC, 125/250VDC, 65kAIC, Series C, G-Frame, Thermal Magnetic Trip, Bolt-On, UL Listed - Essential Electric Supply
GHB3040S1 - Eaton 40A 3-Pole Molded Case Circuit Breaker, 480Y/277VAC, 125/250VDC, 65kAIC, Series C, G-Frame, Thermal Magnetic Trip, Bolt-On, UL Listed - Essential Electric Supply
Roll over image to zoom in Click on image to zoom Images are for reference only
GHB3040S1 - Cutler Hammer/ Eaton/ Westinghouse Bolt-On 40 Amp 3 Pole Circuit Breaker - Essential Electric Supply
GHB3040S1 - Eaton 40A 3-Pole Molded Case Circuit Breaker, 480Y/277VAC, 125/250VDC, 65kAIC, Series C, G-Frame, Thermal Magnetic Trip, Bolt-On, UL Listed - Essential Electric Supply
GHB3040S1 - Eaton 40A 3-Pole Molded Case Circuit Breaker, 480Y/277VAC, 125/250VDC, 65kAIC, Series C, G-Frame, Thermal Magnetic Trip, Bolt-On, UL Listed - Essential Electric Supply
GHB3040S1 - Eaton 40A 3-Pole Molded Case Circuit Breaker, 480Y/277VAC, 125/250VDC, 65kAIC, Series C, G-Frame, Thermal Magnetic Trip, Bolt-On, UL Listed - Essential Electric Supply

Description

GHB3040S1


GHB3040S1 is a three-pole, 40A molded case circuit breaker from Eaton, designed for robust electrical protection in commercial and industrial applications.

This Eaton Series C, G-frame breaker features a fixed thermal magnetic trip unit, bolt-on mounting, and is rated for 480Y/277VAC and 125/250VDC systems. It offers high interrupting capacity with 65kAIC at 240VAC and 14kAIC at 480Y/277VAC, ensuring reliable performance under fault conditions. The breaker is UL listed and meets federal specifications for safety and compliance.

    Key Specifications
  • Part Number: GHB3040S1
  • Manufacturer: Eaton
  • Amperage: 40A
  • Voltage: 480Y/277VAC, 125/250VDC
  • Poles: 3
  • Mounting Type: Bolt-On
  • Interrupt Rating: 65kAIC at 240VAC, 14kAIC at 480Y/277VAC
  • Series/Frame: Series C, G-frame
  • Trip Unit: Fixed thermal magnetic
  • Termination: Screw terminal (line side)
  • Certifications: UL Listed, meets Federal Specifications
  • Application: Commercial, industrial power distribution

At Essential Parts(more...)

Specifications

  • Part Number: GHB3040S1
  • Manufacturer : Eaton
  • Brand : Cutler Hammer
  • Category : Circuit Breaker
  • Item Subcategory : Molded Case
  • Family : Series C
  • Type : GHB
  • Voltage : 480
  • Amperage : 40
  • Phase : 3
  • Poles : 3
  • AIC rating : 14kA@480V
  • Connection : Bolt-On
  • Functions : LI - Long-Time and Instantaneous Trip
  • Terminal Connection : Screw Clamp
  • Frame Size : 100/GHB
  • Temp Rating : 28-158 ¡F (-2-70 ¡C)
  • Breaker Type : Standard
  • Protection : Thermal Magnetic

Product Data

  • UPC : 786679029794
  • GTIN : 00786679029794
  • Country of Origin : Dominican Republic
  • Dimensions : 2.63 in x 4 in x 3 in (Length/Depth x Height x Width)
  • Weight : 1.75
  • Panel Type : Eaton Powerline Panelboards
  • Standards : UL 544
  • Certification : CSA Certified, UL Listed

Accesories

Part Manufacture Sub Category
1288C75G03
F0S03C
1373D62G01
